Welcome to Wireless Livestreaming
Break free from the complicated setup and tangle of cables typically needed to connect cameras, computers, and switchers for multi-camera livestreaming. With just an iPad and a few mobile phones, the revolutionary Roland AeroCaster system will have you wirelessly switching and streaming on your favorite platform in minutes.

Features

• Powerful wireless production solution with hardware control surface/audio interface and full-featured iPad app
• Switch up to four wireless devices simultaneously, plus the camera on the host iPad
• Supports wireless camera connections from up to four supported iOS and Android smartphones and tablets
• Wirelessly share screens from computers and mobile devices via the Google Chrome web browser
• Switch between cameras, media, and scenes with a variety of transition effects
• Save and recall 30 scenes with titles, graphics, and picture-in-picture windows
• Media pool for integrating video, audio, photos, and graphics stored on your iPad
• Stream directly to YouTube, Facebook Live, Twitch, and custom RTMP channels over Wi-Fi or 4G/5G cellular networks
• Intuitive hardware control surface and audio interface with two XLR inputs, 3.5 mm stereo input, and headphones and monitor outputs

Specs

• Connectors
• MIC 1, 2 jacks: Combo type (XLR, 1/4-inch TRS phone), balanced, phantom power (DC 48 V, 4 mA Max)
• LINE IN jack: Stereo miniature type
• MONITOR OUT jack: RCA phono type
• PHONES/HEADSET jack: Stereo miniature type (Stereo, CTIA-type)
• DC IN 5V port: USB Type-C (R)
• DEVICE port: USB Type-C (R)
• Controller

• MIC 1 LEVEL fader
• MIC 2 LEVEL fader
• LINE IN LEVEL fader
• MAIN LEVEL fader
• MIC 1 COMP/LIMITER knob
• MIC 2 COMP/LIMITER knob
• MIC 1 GAIN knob
• MIC 2 GAIN knob
• LOOP BACK knob
• HEADSET/ONBOARD MIC knob
• REVERB knob
• LIP SYNC DELAY knob
• PHONES/HEADSET knob
• MIC 1 +48V switch
• MIC 2 +48V switch
• Indicator

• POWER
• DEVICE
• SIG/PEAK
• Nominal Input Level

• MIC 1, 2 jacks: -60 to +4 dBu (Maximum input level: +24 dBu)
• LINE IN jacks: -10 dBu (Maximum input level: +10 dBu)
• Input Impedance

• MIC IN 1, 2 jacks: 10 k ohms (ANALOG GAIN < 24 dBu), 5 k ohms (ANALOG GAIN < 24 dBu)
• LINE IN jacks: 15 k ohms
• Nominal Output Level

• MONITOR OUT jacks: -10 dBu (Maximum output level: +10 dBu)
• PHONES/HEADSET jack: 15 mW + 15 mW (32 ohms load)
• Output Impedance MONITOR OUT jacks: 1 k ohms

• Audio Effects Delay, Reverb, HPF, Noise Gate, De-Esser, Compressor, Limiter
• Power Supply

• USB AC adaptor (commercially available)
• * Recommended to use an USB AC adaptor that can supply 5V, 1.0 A or more.
• USB Bus power
• Current Draw

• 700 mA (AC adaptor)
• 500 mA (USB bus power)
• Operation Temperature

• +0 to +40 degrees Celsius
• +32 to +104 degrees Fahrenheit
• Dimensions

• 220(W) x 166(D) x 60(H) mm
• 8-11/16(W) x 6-9/16(D) x 2-3/8(H) inches
• Weight (without cables)

• 600 g
• 1 lb 6 oz
• Accessories

• Leaflet "Read Me First"
• USB Type-C to Lightning cable
• USB Type-C to USB Type-A cable
• * 0 dBu = 0.775 Vrms

• AEROCASTER LIVE

• Video Input
• Satellite camera
• Browser source
• Built-in camera (iPad).
• * 5 inputs in total
• * Satellite cameras can be used with AeroCaster Camera or Web browser.
• * Need to install the “AeroCaster Camera” App on your iPhone and Android Phone.
• * “Browser source” use PC or mobile devices (iOS, Android OS) via Google Chrome web browser.
• * Codec:H.264 Bitrate:Up to 20Mbps
• Video Processing
• RGB 4:4:4, 8-bit
• 1080/60p
• * Depends on iPad internal processing
• * Video input will be converted automatically.
• Input Formats

• Up to 1080/30p
• * Automatically adjusts resolution and frame rate according to network bandwidth.
• Output Formats

• Up to 1080/60p
• * Reccommend Apple USB-C Digital AV Multiport Adapter or Apple Lightning-Digital AV Adapter.
• Still image and video and audio playback

• Up to 100.
• * Use still images and videos saved in the iPad.
• * File format conforms to iOS Photo Library.
• * PNG alpha channel supported.
• * Support mp4(aac), m4a(aac), mp3, wav as audio source.
• Scene

• Up to 30.
• * Text, Media (Overlay), PinP, SPLIT, QUAD are either can be registered.
• Video Effects

• Transition: CUT, MIX (DISSOLVE), WIPE
• DSK (overlay): Text, Media
• Composition: PinP, KEY (Luminance Key, Chroma Key), Simple telop function
• * PNG alpha channel composition supported
• Audio Processing Sampling Rate: 24 bits, 48 kHz

• Streaming Platform

• YouTube Live
• Facebook Live
• Twitch
• * Custom RTMP supported
• Recording

• Format : MP4 (H.264/AAC)
• Bitrate : 1Mbps〜10Mbps
• Other Functions

• (Zoom, Exposure, White Balance, Focus, LED Light, Stabilization)
• * Depends on smart phone or tablet
• OPERATING CONDITIONS

• AeroCaster LIVE (for iPad)
• Operating System:
• iOS 14 or later
• CPU: Apple A12 processor or better (A12Z or better is recommended)
• AeroCaster Camera (for iPhone, iPad)

• Operating System:
• iOS 13 or later
• CPU: Apple A10 processor or better (iPhone 7 or higher recommended)
• AeroCaster Camera (for Android)

• Operating System:
• Android 10 or later
• CPU: Models with H.264 hardware encoder
• Others:
• Screen resolution 1280x720 or higher
• Equipped with two or more cameras in front and rear
