FANTOM-0 brings your creative world together, combining the sonic power and fluid workflow of the top-of-the-line FANTOM series in streamlined instruments that go everywhere your inspiration takes you.

Equipped with an expressive 88-note keyboard with weighted action, FANTOM-08 has everything you need to create and perform at the highest level. Play and produce with thousands of Roland’s best sounds and unleash your musical vision with a color touchscreen, hands-on controls, and deep computer integration derived from the flagship models.

Specs

• KEYBOARD
• Keyboard 88 Keys (PHA-4 Standard Keyboard: with Escapement and Ivory Feel)
• SOUND GENERATOR
• TONE
• ZEN-Core
• SuperNATURAL Acoustic
• SuperNATURAL Acoustic Piano (EXSN01/03 Preload)
• SuperNATURAL Electric Piano (EXSN02 Preload)
• VTW Organ (Only ZONE2)
• Various MODEL sound generators (Require adding EXM Series)
• * ZEN-Core Tones and Model Tones can import and export.
• * Backup file has compatibility with FANTOM-6/7/8, but it can read the enabled features only.
• Expansion
• EXZ Series
• EXSN Series
• EXM Series
• * The expansion are rewritable internal sound generator memory.

• You can download data from the Roland Cloud and write it via a USB flash drive into the FANTOM's internal memory.
• Parts 16 zones (Internal + External)
• Scenes
• 128 scenes x 4 bank
• * The Scenes can import and export.

• Tones
• 3,500 tones or greater
• 90 Drum kits or greater
• Tone Remain
• 8 zones
• * When "Scene Remain Switch" enabled.
• Tone Remain does not apply to VTW Organ sounds.
• Favorite Rating System: 4 steps (0-3)
• Tone Search/Scene Search Rating, Character
• Effects
• Multi-Effects: 16 systems, 90 types
• Part EQ: 16 systems
• Drum Part COMP: 6 systems
• Insertion Effect: 2 systems, 90 types (Serial/Parallel connection selectable)
• TFX: 1 system, 90 types
• Input MFX: 1 system, 90 types
• Chorus: 9 types

• Reverb: 7 types
• Master Compressor
• Input Reverb: 7 types
• Input EQ: 1 system
• Vocoder
• Band: 13, 20, 32
• Type: Mono, Stereo
• Preset Setting: 10
• User Setting: 20
• Scene Chain

• Chain: 16 Scenes x 32 Pages (Total 512 Scenes) per 1 Chain set
• Set: 100
• Marker: 36 (0-9, A-Z, a-z) per 1 Chain Set
• PATTERN SEQUENCER

• MIDI Tracks 16
• Group 16
• Pattern 8 (per each track)
• Pattern Length 64 measures
• Recording Method Realtime recording, Step recording, TR-REC
• Editing Method Piano roll edit (Touch Edit/Automation support), Microscope
• Song 1 (per Scene)
• File format Original, SMF export/import supported * PAD Sampler trigger data can be recorded.
• SMF PLAYER
• Format SMF (Format 0/1)
• MIDI tracks 16
• Tempo range 5-300 BPM
• Transpose function -5-+6 semitone
• Track Mute Yes
• Track Solo Yes
• A/B loop function Yes
• * The pattern sequencer and SMF player can be used in each scene. They cannot be used at the same time.
• SAMPLER - KEYBOARD MULTISAMPLE
• Format 16/24-bit linear, 44.1/48 kHz, WAV/AIFF import supported.
• Number of Samples 2,048
• Number of Multisamples 128
• Sampling Time The maximum is 2 minutes 44 second (1 Sample).
• * A total of approximately 256 MB (Share with Expansion titles)

• * Keyboard Multisample can import and export as ZEN-Core Tone.
• SAMPLER - PAD SAMPLER
• Format 16/24-bit linear, 44.1/48 kHz, WAV/AIFF import supported
• Maximum Polyphony 8
• Number of Samples 16 pads x 4 banks
• Sampling Time The maximum is 60 minutes (the equivalent of approximately 660 MB).
• * A total of approximately 2 GB (including imported WAV files)

• * When you use the PAD samples as KBD Wave, then you have to manipulation it.
• SAMPLER - INTERNAL STORAGE SPACE FOR FILES
• Size 2 GB
• OTHERS
• Rhythm Pattern Yes
• Arpeggiator Yes
• Chord Memory Yes
• Motional Pad Yes
• PAD Mode Sample Pad,Note Pad,Partial Sw/Sel,DAW Control,Zone Mute,Zone Solo,Kbd Sw Group,Rhythm Pattern,Pattern,Variation Play,Group Play
• AIRA LINK * When connect to MX-1
• Controllers
• Pitch Bend/Modulation lever *1
• Assignable Switch x 2 (S1/S2)
• Control knob x 8
• Slider x 8
• Wheel x 2 *1
• Function knob x 6
• Sound Modified knob x 2 *1
• 4 x 4 Pad
• *1: 1,024 step editing support
• It can be use with Cutoff, Resonance.
• Display Graphic Type, 5.5" (1,280 x 720 dots), backlite LCD (Color/Touch screen, Screensaver, Wallpaper support)
• Audio Interface
• Max 24 bit/96 KHz
• Record 16 Stereo Channel
• Playback 2 Stereo Channel
• External Memory USB Flash drive (sold separately)
• Power Supply AC Adaptor
• Power Consumption 1,300 mAh
• Accessories
• Owner's Manual
• AC adaptor
• Options (sold separately)
• Keyboard Stand:
• KS-G8B, KS-10Z, KS-12, KS-20X
• Pedal Switch: DP series, RPU-3
• Expression Pedal: EV-5
• USB Flash drive
• SIZE AND WEIGHT
• Width 1,393 mm 54-7/8 inches
• Depth 354 mm 13-15/16 inches
• Height 138 mm 5-7/16 inches
• Weight 14.8 kg 32 lbs 11 oz
